Rotary Dry Syrup Powder Filling and Rubber Stoppering Machine

The Rotary Dry Syrup Powder Filling and Rubber Stoppering Machine is specially designed for the high-volume filling of dry syrup powder into bottles, along with secure rubber stoppering. Constructed to accommodate different bottle materials—glass, PET, HDPE, and LDPE—this solution is the right choice for pharmaceutical manufacturers in need of rapid, hygienic, and cGMP-compliant performance.

Powder Filling and Rubber Stoppering Machine Video

Sterile Built with Robust Construction

Fabricated from SS 316L contact parts, the Rotary Dry Syrup Powder Filling and Rubber Stoppering Machine is made of stainless steel construction and built in accordance with GMP and FDA standards. The seamless design provides a reduced contamination risk and is compatible with cleanroom integration and easy sterilization, allowing compliance with aseptic manufacturing protocols.

​

How It Works?

• Bottle Feeding: Bottles are automatically indexed onto the rotary platform via an infeed star wheel.

• Bottle Positioning: A rotating turret reliably positions bottles beneath the powder-filling nozzles.

• Powder Dosing: A rotary dosing wheel and auger system dispense powder into bottles at the desired quantity.

• Rubber Stoppering: Post-filling, rubber stoppers are placed in the bottles using a synchronized pressing mechanism.

• Outfeed: Stoppered bottles are then passed automatically to the next stage of the packaging line.

• Continuous Monitoring: The system shuts down automatically when the pressure in the air tube is low, or when vacuum is present, for safety and consistency. (optional)

​

Key Features of Dry Syrup Powder Filling Machine

• No Bottle – No Fill System guarantees no product waste.

• The rotary funnel system works with the rotary bottle movement for synchronized and continuous filling.

• Vibratory funnel mechanism for Semi-Free Flow Powders at higher rates.

• This machine features disassembly of contact parts and was specifically designed for simple cleaning, sterilization, and maintenance.

• The machine structure is made of SS304 for strength, durability, and cleanroom suitability.

• Filling accuracy up to ±2 to 3% based on powder consistency and controlled RH.

• Star wheel-based infeed and outfeed means automatic bottle handling.

• The Auto Start/Stop function stops the machine when no bottle is detected at infeed.

• The Low Air & Vacuum Detection System pauses the operation if the parameters fall out of spec, keeping the operation safe.

• Safety and visibility through a toughened glass cabinet.

The dust extraction Blower keeps the filling area clean and free of contamination.

Model-Specific Differences:

Model: AI-DPM 12

• Output Capacity: Up to 80 bottles per minute

• Dimensions (L x W x H): 1700mm x 1000mm x 1800mm approx.

Model: AI-DPM 16

• Output Capacity: Up to 120 bottles per minute

• Dimensions (L x W x H): 2000mm x 1200mm x 1800mm approx.

Technical Specification of Dry Syrup Powder Filling Machine

* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.

The Rotary Dry Syrup Powder Filling and Rubber Stoppering Machine is a compact yet high-performing unit built to maximize speed, precision, and hygiene in dry syrup production. Its smart features and robust design make it an indispensable solution for pharmaceutical packaging lines.

​
